Avinci CX3200
Dye sublimation roll-to-roll printer that prints on a wide range of polyester-based media
Agfa’s dedicated dye sublimation roll-to-roll printer will enable you to create vibrant high-quality prints on polyester-based fabrics up to 3.2 m wide, including a broad range of in- and outdoor soft signage applications, as well as interior decoration. The Avinci CX3200 is a highly reliable and convenient soft signage printer that is able to print directly to fabrics, as well as onto transfer paper. It uses an off-line calender unit to ensure perfect fixation.
主要优势
- High productivity and a robust design for reliable printing at all times;
- Vibrant prints and a wide color gamut;
- Excellent print quality and fine detail rendering;
- Extensive applications scope;
- Low ink consumption;
- Convenient operations and a fast changeover between jobs;
- Complete and integrated solution: printer, inks, workflow software, worldwide service and applications support
Direct & transfer printing – for the widest application scope
Avinci can print a wide variety of polyester-based soft signage applications such as backlit point-of-sales displays, indoor wall graphics, outdoor advertising, block-outs, backdrops, flags, or retail store décor elements. In addition, it can also be used to print polyester-based sportswear or fashion garments. You name it, Avinci is up to the challenge.
- Being able to print directly to fabric is easy and ideal for fast handling and for special applications such as flags, where print-though is needed.
- Transfer paper allows for super sharp prints, eliminates any set-off, and limits media waste to a minimum. In addition, it extends the application scope to sportswear and fashion garments, as well as home décor prints on non-coated polyester fabrics.
Vivid colors, high performance
The Avinci CX3200 boasts a rich color gamut and delivers deep black, perfect solids, accurate spot color mapping and smooth tonal rendering that is particularly noticeable in skin tones. Through the process of dye sublimation, your soft signage prints will look simply amazing.
The Avinci inks are characterized by their flexibility, image longevity and outdoor resistance. They offer stable jetting performance and deliver the same high-quality results, batch after batch.
An off-line calender unit fixes the color deeply into the structure of the polyester-based fabrics while evaporating the carrier fluid.
Low ink consumption saves money
Avinci produces excellent results with a minimum of jetted ink. This low ink consumption is based on Agfa’s renowned Thin Ink Layer technology: a smart combination of particular ink characteristics and our Asanti workflow software algorithms that tune the ink quantities perfectly to the required image quality mode.
Reliable and convenient – for maximum uptime and peace of mind
Smooth and accurate media handling
The Avinci’s dedicated soft signage transport system ensures precise and flawless unwinding, feeding and winding of media, even at the highest production speed. When printing on transfer paper, the vacuum plates make sure that the media are kept perfectly flat on the table and will not wrinkle. The powerful drying system limits drying time and reduces set-off.
Fast and easy changeover
You will not find a textile printer that is as easy to use as the Avinci. Thanks to the convenient pinch rollers and foot pedal, loading a new roll can be done in less than seven minutes by a single operator!
Robust design & low maintenance
The Avinci CX3200 has a robust design, using only high-quality parts that are built to last. This means you can expect few service interventions and a minimum of consumables consumption. Maintenance is minimal and easy too.
Watch the movie
Related articles
Powered by Asanti workflow software
The Avinci CX3200 is driven by Agfa’s Asanti wide-format workflow software. Asanti controls and automates the entire printing process from file intake to finishing, maximizing productivity. Its comprehensive integration of file handling, color management and preflighting guarantees smooth and error-free jobs.
Color accuracy is provided by the easy-to-use color management. Using our Calibrated Print Mode feature, new media can be calibrated and profiled in less than 15 minutes, after which the new profiles can be used to guarantee print quality. In addition, Asanti’s smart imaging algorithms help optimize ink consumption, and consequently reduce your production costs as well as your environmental footprint.
The web-based Asanti Production Dashboard offers a view on your running production. It summarizes the jobs produced and reports on quantity printed, media usage, ink volumes… enabling you to control your production and to manage your print shop optimally
Smart business software solutions
World-class training and support, anywhere you need it
Technical Specs
| Media & printing specifications | |
| Flexible media | |
| Max print width | Single roll = 3.20 m (126.0”) |
| Max roll width | Single roll = 3.26 m (128.5”) |
| Maximum length | >100 m length (also depends on the thickness and total roll weight) |
| Max media thickness | Max. 3 mm (0.12”) |
| Maximum weight | Single roll in full width: 220 kg (485 lbs) |
| Maximum roll outside diameter | 300 mm (11.8”) |
| Roll mounting | Pneumatic shafts for core diameter 7.62 cm (3”) (standard) |
| Media skew | Max. 2 mm on 10 m printing |
| Borderless printing | Single roll = up to 3.2 m (126”) |
| Media transportation | Dancer bars and print plate suction for roll-to-roll |
| Productivity | |
| Open fabric: in-& outdoor flags Closed fabrics: displays |
70 to 270 m2/h (753 to 2906 ft2/h) |
| Closed fabric with diffusion layer: backlit displays | 35 to 110 m²/h (377 to 1184 ft²/h) |
| Transfer paper | 70 to 270 m2/h (753 to 2906 ft2/h) |
| Media | |
| Media types | Polyester-based fabrics, or transfer paper used to create banners, indoor wall graphics, shop decoration, outdoor advertising, light boxes, trade show displays, flags and high polyester-based blends |
| Print heads & inks | |
| Print heads | Kyocera KJ4B-0300 |
| Ink | CMYK |
| Ink system maintenance | Automatic |
| Image & text quality | |
| Image quality | Resolution up to 600 x 1800 dpi |
| Engine dimensions & weight | |
| Printer dimensions & weight (W x D x H) |
Uncrated: 5240 mm x 1200 mm x 1700 mm (207” x 47.2” x 66.9”)
Crated: 6490 mm x 1840 mm x 2160 mm (256” x 73” x 85”) |
| Printer weight | Uncrated: 1280 kg (2822 lbs)
Crated: 2100 kg (4630 lbs) |
| Room conditions | |
| Temperature | 20-25°C |
| Relative humidity | 40-80% |
| Electricity & compressed air | |
| Electricity | Engine: single phase 220-240 VAC (50/60 Hz) 12A (Fuse 16 A)Dryer: single phase 220-240 VAC (50/60 Hz) 28A (Fuse 30 A) |
| Compressed air | Dry and oil-free (Class 1 according to ISO 8573-1 2010) 200 l/min – 6 Bar |
| System integration RIP/workflow software | |
| Asanti, PrintSphere, third-party rips | |
Media list
The Avinci CX3200 can handle a wide variety of media and applications. This table contains the media that were tested on the printer by Agfa’s inkjet application experts. It lists the ideal printing settings. Of course, many other substrates can be printed on, and the list gets regular updates.
| Printing | Sublimation | ||||
| Brand | Product | Print side | Transfer / Direct | Time +/- (sec) | Temperature (°C) |
| Berger | Display 210 FR | Inside | Both | 40 | 195 |
| GOF | DecoSmart GFS | Inside | Both | 40 | 195 |
| Pongs | Softimage Creaseless | Inside | Both | 40 | 195 |
| TTS | Display Stretch 240 FR | Inside | Both | 45 | 195 |
| TTS | Basic Display 210 FR | Inside | Direct | 45 | 195 |
| TTS | Non-woven Stitch | Inside | Transfer | 45 | 185 |
| Printing | Sublimation | ||||
| Brand | Product | Print side | Transfer / Direct | Time +/- (sec) | Temperature (°C) |
| Aurich | Supernova | Inside | Direct | 50 | 200 |
| Berger | Lumina | Outside | Both | 55 | 195 |
| Soyang | Starlight | Outside | Transfer | 50 | 195 |
| TTS | Polaris Stretch 155 FR | Outside | Both | 50 | 195 |
| TTS | Lightbox Supreme | Inside | Both | 50 | 190 |
| Printing | Sublimation | ||||
| Brand | Product | Print side | Transfer / Direct | Time +/- (sec) | Temperature (°C) |
| Aurich | Beach Flag | Inside | Direct | 45 | 195 |
| Berger | G-Flag 117 FR | Inside | Direct | 45 | 195 |
| TTS | Basic Flag 115 FR | Inside | Direct | 45 | 195 |
| TTS | Basic Beachflag 110FR | Inside | Direct | 45 | 195 |
| Printing | Sublimation | ||||
| Brand | Product | Print side | Transfer / Direct | Time +/- (sec) | Temperature (°C) |
| Pongs | Silencio | Inside | Direct | 45 | 195 |
| Pongs | Akustico | Inside | Direct | 40 | 195 |
| Printing | Sublimation | ||||
| Brand | Product | Print side | Transfer / Direct | Time +/- (sec) | Temperature (°C) |
| TTS | Velvet Fleece Sheep 435 Blanket | Indicated side | Transfer | 45 | 190 |
| Berger | Cosy Blanket | Both | Transfer | 60 | 195 |
| Printing | Sublimation | ||||
| Brand | Product | Print side | Transfer / Direct | Time +/- (sec) | Temperature (°C) |
| JM Textiles | Mediatex Nero FR | Inside | Both | 40 | 195 |
| TTS | Blackback soft FR | Inside | Both | 40 | 195 |
| GOF | BlackBack Stretch | Inside | Both | 40 | 185 |
| Printing | Sublimation | ||||
| Brand | Product | Print side | Transfer / Direct | Time +/- (sec) | Temperature (°C) |
| TTS | CARPET 820 | Outside | Transfer | 45 | 190 |
| Printing | Sublimation | ||||
| Brand | Product | Print side | Transfer / Direct | Time +/- (sec) | Temperature (°C) |
| TTS | Poplin 250 | Both | Transfer | 45 | 195 |
| TTS | Trindade 250 | Inside | Transfer | 45 | 195 |
| Printing | Sublimation | ||||
| Brand | Product | Print side | Transfer / Direct | Time +/- (sec) | Temperature (°C) |
| TTS | Bed linen 85 | Inside | Transfer | 45 | 195 |
| Printing | Sublimation | ||||
| Brand | Product | Print side | Transfer / Direct | Time +/- (sec) | Temperature (°C) |
| TTS | Sport Stretch 260 | Both | Transfer | 40 | 200 |
| Printing | Sublimation | ||||
| Brand | Product | Print side | Transfer / Direct | Time +/- (sec) | Temperature (°C) |
| Soyang | Horizon tent | Outside | Transfer | 50 | 195 |
| TTS | Heavy Tent XL 280 FR | Outside | Transfer | 60 | 195 |
| Pongs | Solid tarp | Inside | Direct | 45 | 190 |
| Printing | Sublimation | ||||
| Brand | Product | Print side | Transfer / Direct | Time +/- (sec) | Temperature (°C) |
| TTS | Entre 73 | Inside | Transfer | 45 | 195 |
